Ortur Laser Master H10 Support

related downloads

All downloads related to OLM H10

1. User Manual

The user manual is an instruction manual that describes the functions, installation and use of the laser engraving machine in detail, allowing users to understand how to use the machine.

  1. H10 manual.pdf

2. Laser Module User Manual

The laser module user manual is an instruction manual that details the functions, installation and use of different laser module for the engraving machine.

  1. H10_Exclusive_LU2-10B_Follow_up_Manual.pdf
  2. H10_Exclusive_LU2-4-LF_Follow_up_Manual.pdf
  3. H10_Exclusive_LU2-4-SF_Follow_up_Manual.pdf
  4. H10_Exclusive_-_LU3-20B_Follow_up_Manual.pdf
  5. H10_Exclusive_-_LU3-40A_Follow_up_Manual.pdf
  6. H10_Exclusive_-_LU3-5_Follow_up_Manual.pdf

3. Software Guide

The software guide is to be compatible with more operating systems and devices. Here you can download the software, learn the operation, and obtain parameters.

  • Ortur
  1. Support OS：IOS、Android
  2. Support Machines：OLM3 LE、OLM3、OLM H10、OLM H20、OLM F10、R2
  3. APK Download Link：
  4. User Manual Download Link：Ortur_UserManual_231214.pdf
  • LightBurn
  1. Support OS：Windows、Mac OS、Linux
  2. Support Machines：All Ortur laser engraving machines
  3. Download Link：LightBurn Download link
  • LaserGRBL
    1. Support OS：Windows from XP to Win 11
    2. Support Machines：All Ortur laser engraving machines
    3. Download Link：LaserGRBL Download link

4. Firmware Release


In some circumstances, a firmware update is required to improve the Ortur machine performance or fix discovered issues. In some less common situations, a firmware upgrade might be required to clear issues caused by user error.

  •  ESP_H10_221RC3_20241010
    1. Release Date: October 10, 2024
    2. Version: V221RC3
    3. Update information:
      • Fixed regular upgrade issues
    4. Note: Official Release version
    5. Download Link: ESP_H10_221RC3_241010.bin
  •  ESP_H10_220RC3_20240930
    1. Release Date: September 30, 2024
    2. Version: V220RC3
    3. Update information:
      • Fixed regular upgrade issues
    4. Note: Official Release version
    5. Download Link: ESP_H10_220RC3_240930.bin
  • ESP_H10_219RC3_240125
    1. Release Date: 24 January 2024
    2. Version: V219RC3
    3. Update information:
      • Fixed regular upgrade issues
    4. Note: Official Release version
    5. Download Link: ESP_H10_219RC3_240125.7z




  • ESP_H10_218_231212
  1. Release Date: 23 December 2023
  2. Version: V218
  3. MD5: 5d40748495d1020627712471321fe7d8
  4. Update information:
    • updated the default website for remote updates.
  5. Note: Official Release version
  6. Download Link: ESP_H10 218 231212.zip

5. Firmware Instructions

The firmware Instructions Here are the firmware installation and operation instructions.

  • ESP_H10_218_231212

Download and unzip this file please

Download Link: ESP_H10_218_231212.zip

Extract zip file into desktop.
Inside it, you will see a .bin file

Now with your machine connected via USB to your computer.
Tap the reset button once to turn off your ORTUR

Then do this sequence carefully:

PRESS and hold the reset button on the back of the motherboard. Do not release
Count 3 seconds
PRESS also and hold the power button. Do not release
Count to 3 seconds
Release Reset Button
Count 1 second
Release Power Button

Now your computer will show an ORTUR UPDATE drive – almost as if you had inserted a USB thumb drive
Copy the bin file we extracted earlier into the drive and allow the machine to do its update operation
It will take 30-60 seconds and the machine will home again

Reconnect to LightBurn or LaserGRBL – in the console type where it says (Type commands here) or (Type GCode here)
$RST=*
The machine will respond with
[MSG: restoring defaults]

At this point, you should be ready to use the device.
Note: your wifi settings if you had them will need to be done again

  • Specifications

  • Product Promotion

  • Tutorial videos

  • Support Videos

  • Finished video

Product

Ortur Laser Master H10

Product Material

Auminum

Product DIM.

507*558*130mm

Package DIM.

615*566*85mm

N.W.

4,000g

G.W.

6,210g/6,260g/6,450g/8,150g

Shipping Method

pre-assembled

Product Feature

High-rigidity，Stable

The photoelectric power is related to the laser module supporting the machine.

LU2-4SF

Peak Power: 72w
Optical Power: 5.5w
AC/DC Output: 24V 3A

LU2-4LF

Peak Power: 72w
Optical Power: 5.5w
AC/DC Output: 24V 3A

LU2-10B

Peak Power: 96w
Optical Power: 10w
AC/DC Output: 24V 4A

LU3-20B

Peak Power: 144w
Optical Power: 20w
AC/DC Output: 24V 6A

Motor

Step Motor Nema 17 (X38/Y58mm)

Working Speed

20,000mm/min

Working Area

LR4-2B：X400*Y400mm
LU2-10A：X400*Y400mm
LU3-20A：X400*Y380mm
LU3-40A ：X400*Y380mm

Extension Area（Optional）

/

Mainboard

OLM-ESP-PRO-V2.7

Support Function

WIFI/APP/USB/TF Card

Security Function

1. Active Position Protection
2. Tilting Position Protection
3. USB connection monitoring
4. Host Computer Watchdog
5. Exposure Duration Detection and Limitation
6.Voltage and Current Safety Control System

US

FCC、 FDA 、UL62368

EU

CE-EMC、CE-LVD、 ROHS

Support OS

Android / iOS / Windows / Mac OS / web / Linux

Support Software

LaserGRBL/LightBurn

Support Format

jpg/png/gif/ai/pdf/bmp/dxf/gcode/plt/svg

Engraving Material

Medium Density Fiberboard (MDF), Plywood, Pine Wood, Paulownia Wood, Cardboard, Paper, Kraft Paper, Leather, Dark Acrylic, Cobblestones, Ceramics, Coated Metal, Electroplated Metal, Stainless Steel, Glass, Knitted Fabric, Cotton, ABS Plastic, Bamboo, Silicone, Rubber, Ceramics, Marble, Shale, Cement, Bricks, etc.

Cutting Material

Paper, MDF (Medium - Density Fiberboard), plywood, pine wood, paulownia wood, cardboard, corrugated paper, dark acrylic, PVC (Polyvinyl Chloride), knitting, cotton, ABS (Acrylonitrile - Butadiene - Styrene) plastic, felt, leather, bamboo, silica gel

H10 promotional video

H10 20W Acrylic Test

H10 Stainless Steel Test

H10 20W plywood testing

H10 plywood cutting test

H10 unboxing installation tutorial

H10 adjusting eccentric nut

H10 belt adjustment tutorial

Tutorial on installing Z-axis lifting device on H10

Installation of H10 LU3-20B laser module and air pump

H10 connection IOS APP operation video tutorial

Video tutorial on how to connect H10 to Android mobile APP

H10 uses LaserGRBL parameter settings and usage tutorials

H10 uses LightBurn parameter settings and usage methods

H10 belt replacement

H10 motherboard replacement

H10 Automatic Return Exception Solution

H10 Replace L-shaped plate

H10 Christmas Glass Carving

H10 makes storage boxes

H10 stainless steel tableware carving

H10 connects YRC1.0 engraved glasses and glass bowls

H10 connects YRR2.0 engraving pen holder and roller rolling pin

H10 connects YRR3.0 engraved wine glass and baseball bat
Title

faq

Can it solve your problem?

1. Why the H10 20W is suitable for beginners?

✅ H10 20W comes in preassembled package - right outside the box.

✅ Work with Smart APP to make the operation easier.

✅ Free air assist included at no extra cost.

2. I am a experienced player, should I buy the H10 20W?

Of course.
Besides the convenient design, H10 equipped with 20W professional laser module, meeting most of the engraving & cutting needs.

3. What are the advantages of the flat structure?

With the innovative flat design, module's centre of gravity is lowered for more stability during movement, bringing ultra-high accuracy.

4. Can I change other modules on the H10?

Yes, H10 can be directly adapted toLU3-20A/B, LU2-10A, LU2-4SF/LF, LU2-2.

5. Which accessories are recommended for H10?

✅ The Air Assist Set and Engraving Platform are must-haves. Air Assist Set blows away the dust on the laser head, making your project clean without burn marks and protective lenses.

✅ Processing on honeycomb avoids laser shooting at your desk. 90% of users also order YRC1.0 for cylindrical processing, like tumbler engraving, Christmas ball crafting, and ring engraving.

✅ The H10 exclusive raiser (ORP1.0) is an essential assistant to the Y-Series rollers, and it can also be stacked indefinitely to engrave super-tall objects.

✅ Use indoors with Enclosure 2.0 and a smoke purifier to protect clean indoor air.

6. What is the difference between the LU3-20A and LU3-20B?

✅ LU3-20A packed with COS technology, which has the best cutting capacity in current Ortur modules.

✅ LU3-20B assembled with optical compression technology, which can handle the majority of thick materials

7. How many sets of H10 raisers should I usually have?

Normally, one set of H10 raiser is sufficient to fit all Y-series rollers of Ortur. However, if you need to engrave larger cylinders and spheres, or thicker, flat objects, you can purchase the raisers separately depending on their size and your needs.
